DURO PLUG

Polymer based, Un-sanded cement grout for interior & exterior, floor & wall joints of width l mm - 3 mm. Our commitment to waterproofing and bonding material manufacturing and supply in Andhra Pradesh is demonstrated through DURO-PLUG, an advanced crystalline waterproofing compound designed for immediate water stoppage. This rapid-setting hydraulic cement represents the culmination of extensive research in waterproofing technology.

Features / Benefits

  • Emergency water - stopping capability
  • Single component - only the addition of clean water is required
  • Excellent bond to the substrate
  • Low exo-therm minimises thermal cracking
  • Pre-packed formulation to overcome variation in site batching
  • Contains no chloride admixtures

Application

DURO PLUG is supplied as a ready to use blend of dry powders which requires only the addition of clean water at site to produce a highly consistent, rapid setting mortar which is easy to apply in many difficult conditions. The material is based on a blend of cements, graded aggregates, special fillers and chemical additives which control the rate of set and minimise the risk of thermal cracking.

Packages

  • 1Kg - Retail Pack
  • 5Kg-Project pack
  • Colors

    1. Gray

    Uses

    1. Rapid setting cement based, water leak plugging mortar
    2. For the rapid temporary patching and plugging of concrete segments, concrete and brick tunnel linings, sewage systems, below ground access chambers, pipes, basements, founda­ tions and mines.

    Certification

    Areas to be patched should be cut back to a depth of 15mm and given a good mechanical key. Feather edges must not be allowed. Surface should be brushed clean to remove loose material, dust and laitance, grease, slime or mould growth should be removed by steam cleaning or high pressure water jetting. A proprietary degreasing agent should be used for removal of light oil or grease contamination. To seal leaks, crack openings must be chased out to approximately 20mm. The chase should always be undercut to avoid leaving a V-section. All loose material and debris should be removed.

    Mixing:

    DURO PLUG should be added to clean water in the following proportions : One part clean water : 3 parts DURO PLUG (measured by volume).Mix to a stiff consistency in a suitable container using a trowel or gloved hand. Due to the rapid set characteristics of the product, only prepare a quantity of mortar which can be placed within the prescribed set time.

    Technical Properties
    • Setting Time: 3-5 minutes at 20°C
    • Expansion Rate: 0.1% positive expansion
    • Compressive Strength: >4,000 PSI after 28 days
    • Bond Strength: >220 PSI to concrete
    • Water Pressure Resistance: Up to 7 bar
    Applications
    • Active water leak repairs
    • Basement waterproofing
    • Underground structures
    • Elevator pits and foundations
    • Water tanks and reservoirs
    • Tunnel and subway systems
    • Marine structures
    Advanced Features
    • Instantaneous water-stopping capability
    • Non-shrink, non-metallic formulation
    • Excellent bond to concrete and masonry
    • Durable crystalline formation
    • Non-toxic and environmentally friendly
    • Compatible with all waterproofing systems

    Application instructions
    Preparation :

    Precautions
    Health & Safety :

    DURO PLUG contains cement powders which, when mixed or become damp, release alkalis which can be harmful to the skin. During use, avoid inhalation of dust and contact with skin and eyes. Wear suitable protective clothing, gloves, eye protection and respiratory protective equipment. The use of barrier creams provide additional skin protection. In case of contact with skin, rinse with plenty of clean water, then cleanse with soap and water. In case of contact with eyes, rinse immediately with plenty of clean water and seek medical advice. If swallowed, seek medical attention immediately - do not induce vomitting

    Specification clauses
    Water stopping mortar :

    The water stopping mortar DURO PLUG, a single component cement based product to which only the site-addition of clean water shall be permitted. It must be chloride free and shall have a low exo-therm to minimise thermal cracking

    Description

    DURO PLUG is supplied as a ready to use blend of dry powders which requires only the addition of clean water at site to produce a highly consistent, rapid setting mortar which is easy to apply in many difficult conditions. The material is based on a blend of cements, graded aggregates, special fillers and chemical additives which control the rate of set and minimise the risk of thermal cracking.

    Technical support :

    DUROXZ offers a comprehensive range of high performance, high quality concrete repair and construction products. In addition, DUROXZ offers technical support service to specifiers, end users and contractors, as well as on-site technical assistance in locations all over the country

    Properties

    Initial set time Approx. 1 - 2 mins. at 30°C Compressive strength : 25N/mm2 @ 28 days @ 30°C Heat generation characteristics : High heat output (exo-therm) leads to undesirably high shrinkage and consequent thermal cracking. The curves below show the low heat output of DURO PLUG which minimises the risk of shrinkage and thermal cracking

    Design criteria :

    DUROXZ can be applied to horizontal, vertical or overhead surface at a wide range of thickness. Generally, the volume of mixed material used in a single application is restricted to that which can be applied by trowel or gloved hand. Thicker sections can be built up in layers. If any doubt arises about the nature of the substrate, consult the local DUROXZ office for further information.

    Limitations :

    DURO PLUG should not be used when the temperature is below 10°C and falling.

    Cleaning:

    DURO PLUG should be removed from tools, equipment and mixers with clean water prior to the initial set. Cured material can only be removed mechanically.

    Application :

    Trowel apply or hand-knead the mixed mortar in place, ensuring maximum contact with the substrate before the material sets. If being used to plug running water, DURO PLUG should be used and held in place until the initial set is reached

    Important note

    DUROXZ products are guaranteed against defective materials and manufacture and are sold subject to its standard terms and conditions of sale, copies of which may be obtained on request. Whilst DUROXZ endeavours to ensure that any advice, recommendation specifi cation or information it may give is accurate and correct, it cannot, because it has no direct or continuous control over where or how its products are applied, accept any liability either directly or indirectly arising from the use of its products whether or not in accordance with any advice, specification, recommendation or information given by it.
